BE-M[2.0] SERIES

DC CHARGING STATION

150kW dc CCS2+CCS2 7,5m

Cod. 206.M41-I1608

BE-M[2.0] Series
DC CHARGING STATION
150kW dc
AC 3P+N+E 400V 50/60Hz 230A
CCS2+CCS2
CCS2 150-1000Vdc 375A
CCS2 150-1000Vdc 375A
7,5m
YES
94% to nominal power
0,99
A
IP55
-25°C +40°C (55 with derating)
2000m max
5% to 90% non condensating
<55dB in all directions
VARNISHED METAL
IK10
DARK GREY
ON TURRET
Resistant
UV resistant
735x640x1866mm

Product

EAN code
INTRASTAT code
8504406090
Net weight
0 KG
Minimum Quantity
0
EN 61851-24 (2014) [European Standard] Electric vehicle conductive charging system - Part 24: Digital communication between a d.c. EV charging station and an electric vehicle for control of d.c. charging
DIRECTIVE RED 2014/53/EU [European Law] Radio Equipment Directive (2014)
EN 61851-23 (2014) [European Standard] Electric vehicle conductive charging system - Part 23: DC electric vehicle charging station
DIRECTIVE EMC 2014/30/UE [European Directives] Electromagnetic Compatibility Directive
IEC 61439-7 (2018) [International Standard] Low-voltage switchgear and controlgear assemblies - Part 7: Assemblies for specific applications such as marinas, camping sites, market squares, electric vehicle charging stations
DIRECTIVE LOW VOLTAGE 2014/35/UE [European Directives] Low Voltage Directive
EN IEC 61851-1 (2019) [European Standard] Electric vehicle conductive charging system - Part 1: General requirements
TFT 15,6'' push button command
  • Free
  • RFID authentication
  • Ethernet
  • WiFi
  • GSM
OCPP 1.6 JSON
  • identification of authorized user
  • protection against overcurrents and electric shock
  • interfaceable with OCPP 1.6J communication protocol
  • charge in mode 4 CCS2
  • predisposition for network connection
  • measurement and display of energy and current supplied
  • dedicated access to technical support
  • cable management provision
  • DC energy meters
  • 1 reader RFID 13,56MHz
  • Manual stop button
  • 1 ethernet, GSM/3G/4G interface
  • integrated holders
  • 1 service socket
  • 1 TFT 15,6'' display
  • 2 connectors CCS2 with cable 7,5m
thumbnail
UKCA marking
UK Conformity Assessed
thumbnail
UE
Declaration of conformity
* Product image may be indicative
